VYR-962 COLIBRÍ

Impact Pop-up sprinkler

COLIBRÍ pop-up impact sprinkler with 3/4” and 1/2” lower female connection (two in one) and 1/2” side female connection.

Get more information from your nearest distributor

Contact us now

Models

POP-UP VYR-962 WITH SPRINKLER 7 cm PART CIRCLE


Specifications

Reach: 5 - 13 m.
Flow: 450 - 1180 l/h.
Working pressure: 1.5 - 4 bar.
Area: Full or part circle.
Nozzles: Diffuser pin, and with 3 models from 3 mm to 4 mm.
Trajectory angles: 28º.
Maximum stream height: 1.6 m.
Rotation time: 360º between 1 and 4 minutes (adjustable)
Uniformity coefficient higher than 90% in areas of 10x10R, 11x11T, 11x13T

Dimensions

  • Height: 9.45 inches
  • Width: 5.91 inches
  • Weight: 0.88 lb.
  • Units per box: 20
  • Weight per box: 17.64 lb.

Applications

  • VYR-962 COLOBRÍ impact sprinklers are designed and manufactured to offer the best irrigation quality and durability in public gardens, commercial areas, residential gardens and recreational areas.
  • Very versatile model; its design and dimensions are suitable for use with many other similar models on the market, offering security and functionality.

Features

  • COLIBRÍ pop-up impact sprinkler.
  • 3/4” and 1/2” lower female connection (two in one) and 1/2” side female connection.
  • Made of plastic and stainless steel.
  • Teflon, steel and rubber rotation joints.
  • Stainless steel spring with continuous tension.
  • Easily adjustable irrigation area thanks to its internal clip system.
  • Wide range of colour-coded plastic nozzles with the quarter-turn "click" system.
  • Excellent distribution throughout its reach.
  • Removable grit filter for maintenance cleaning.
  • Anti-sand rubber seal.
  • Spring with tension regulation system.

Options

  • Swing pipes for network connection.
  • Maintenance tools.
  • Models with built-in electrically operated valve (24 VAC).
