VYR-968

Rotative overhead sprinkler

Three-arm rotating sprinkler for gardening, agriculture, floriculture and greenhouses.

Get more information from your nearest distributor

Contact us now

Models

ASP VYR-968, 3 BRAZOS CON PINCHO LATON

ASP VYR-968 3 BRAZOS CON PINCHO ALUMINIO

ASP VYR-968, 3 BRAZOS CON PINCHO PLASTICO RACORD 15/20

ASP VYR-968, 3 BRAZOS CON PINCHO PLASTICO RACORD EXPRESS

GIRANDULA 3 BRAZOS LATON CROMADO


Specifications

Reach: 4 - 7 m.
Flow: 360 - 1,044 l/h.
Working pressure: 0.5 - 3.5 bar.
Area: Circular.
Nozzles: A multi-jet nozzle.
Maximum stream height: 2 m.
Rotation time: Irregular
Uniformity coefficient higher than 90% in areas of 5x5R, 6x6T, 6x7T.

Dimensions

  • Height: 13 cm.
  • Width: 12 cm.
  • Weight: 220 gr.
  • Units per box: 10
  • Weight per box: 2.2 kg.

Applications

  • Public and private gardens.
  • Horticultural plantations, floriculture and fruit trees.

Features

  • Three-arm rotating sprinkler for gardening, agriculture, floriculture and greenhouses.
  • Connection of the 3/8” male rotating head, and connection of the spike with a 15 and 20 mm hose coupling.
  • Sprinkler made of chrome-plated brass and copper, and there are three models for the spike: plastic, aluminium and brass.
  • Steel and rubber rotating joints.
  • Three rotating perforated arms and spray sprinklers.
  • Anti-sand filter.
  • This sprinkler is strong and durable enough to work for many years in urban gardens in tough conditions, caused by vandalism and impact from maintenance equipment.

Options

  • Adapter with reduction for 1/2" male.
  • Assembled as a "complete support kit" on aluminium base.
  • Assembled as a "complete support kit" on a 1.3 or 0.7 m galvanized stake with microtube and connectors.
  • Assembled as a "complete support kit" on a 1.3 or 0.7 m galvanized stake with microtube and connectors.

Downloads

This product is not downloaded available
