VYR-80 with galvanized tripod 1/2"

Impact Sprinkler with galvanized tripod

Riser-mounted impact sprinkler for gardening, agricultura, flower growing and greenhouses.

Get more information from your nearest distributor

Contact us now

Specifications

Range distance: 29-46 ft. (9-14 m).
Flow: 121-311 GPH (460 -1,180 l/h).
Working pressure: 22-58 PSI (1,5 - 4 BAR).
Area: Full or part circle.
Nozzles: A multi-jet nozzle.
Trajectory angles: 24º.
Maximum stream height: 9 ft. (2,6 m).
Rotation time: Adjustable. Depending on the pressure and the nozzles, the rotation will be constant and continuous.
Uniformity coefficient higher than 90% in areas of 36x36R, 39x39T, 39x43T ft.

Dimensions

  • Height: 14 cm.
  • Width: 12 cm.
  • Weight: 266 gr.
  • Units per box: 75
  • Weight per box: 20 kg.

Applications

  • Public and private gardens.
  • Horticultural plantations, floriculture and fruit trees.

Features

  • Riser-mounted impact sprinkler for gardening, agricultura, flower growing and greenhouses.
  • 1/2” male connection.
  • Made of brass and stainless steel.
  • High-resistance rotating joints.
  • Arm with anti-splash design.
  • Adjustable deflector plate.
  • Irrigation area system controlled by rotating clips.
  • Adjustable jet breaker diffuser pin.
  • This sprinkler is strong and durable enough to work for many years in urban gardens in tough conditions, caused by vandalism and impact from maintenance equipment.

Options

  • Special design with a threaded shaft for fitting to the VYR-961 pop-up head.
  • Self-compensating flow control valves of 22-29 PSI (1,5-2 BAR).
  • Assembled as a "complete support kit" on a 3.3 or 1.7 ft. galvanized stake with microtube and connectors.
  • Assembled as a "complete support kit" on a brass, aluminium or plastic spike.
  • Assembled as a "complete support kit" on an aluminium base.
